Spec
- Transducer type
- True condenser
- Operating principle
- Pressure gradient
- Frequency response
- 40 ... 20,000 Hz
- Polar pattern
- Cardioid
- at 1 kHz (0 dB = 1 V/Pa)
- 30 mV/Pa = -30.5 dBV
- Nominal impedance
- 180 Ω
- Load impedance
- 1000 Ω
- Max. SPL at 1 kHz
- 125 dB
- with pre-attenuation
- 140 dB
- Signal-to-noise ratio rel. to 1 Pa
- 71 dB
- A-weighted equivalent SPL
- 16 dB
- Low-cut filter
- switchable, 6 dB/octave at 250 Hz
- Power supply
- 11 - 52 V phantom power
- Current consumption
- 4.6 mA
- Connection
- 3-pin XLR male
- Length
- 128 mm
- Diameter
- 21 mm
- Weight without cable
- 115 g
