Spec
General Specification
- Revered equalization circuitry derived from classic 8108 design and flagship 88RS analogue console
- Hand-built and hand-wired by Neve in Burnley, England
- ±20dB Input trim
- USB port for recall of settings via Mac or PC and control software
- XLR input combination jack, +4dBu, -10dBV
- XLR and parallel jack outputs
- External 100V-250V power supply
EQ Specification
- High pass filter 30Hz-300Hz, 12dB per octave
- Low pass filter 3kHz-15kHz, 12dB per octave
- EQ High 1.5k-18kHz, selectable Shelving/Bell, selectable Hi Q
- EQ Mid High 0.8kHz-9kHz, Q range: 0.3 to 7 continuously variable
- EQ Mid Low 120Hz-2kHz, Q range: 0.3 to 7 continuously variable
- EQ Low 33Hz-440Hz, selectable Shelving/Bell, selectable Hi Q
- EQ bypass switch
Audio Performance
- Max Output Level: +26dBu
- Frequency Response: +/- 0.3dB 10Hz – 20kHz+/- 0.5dB 10Hz – 35 kHz
- Outputs: Max +26dB into 600 Ohms. Zout 75 Ohms ±5% @ 1kHz, balanced and earth-free An unbalanced output 8dB below the level of the balanced output is also provided.
- Distortion: <0.006 (10Hz to 20kHz using window of 10hZ – 80kHz)
- Noise: <80dB 20hz - 20kHz (Using measurement window of 10hZ – 22kHz)
- Input Impedance: >20k Ohms
- Output Impedance: 50 Ohms
Dimensions
- Width: 48.2cm
- Height: 4.4cm
- Depth: 24cm – without power socket plugged in.
- Weight: 2.5kg
