Spec
Inputs
- Connectors
- 3 pin XLR (pin 2 hot)
- Impedance
- Balanced: 21 kOhm, Unbalanced: > 10 kOhm
- Max. Input Level
- 24 dBu
- Sensitivity Range @ full scale
- 0 dBu to 24 dBu
- Connectors
- 3 pin XLR (pin 2 hot)
- Impedance
- 40 Ohm
- Max. Output Level
- Balanced: 20 dBu / Unbalanced: 14 dBu
- Output Ranges
- Balanced: 20/14/8/2 dBu / Unbalanced: 14/8/2 dBu
- Max. Load
- 1200 Ohm @ Output Level > 14 dBu, 600 Ohm @ Output local < 14 dBu
Performance
- Conversion
- 24 bit (1 bit, 128 times oversampling)
- Conversion Delay alone
- 1.38 ms
- Dynamic Range (#)
- Typ. > 102 dB, 20 Hz - 20 kHz
- THD
- Typ. < -90 dB (0.0032%) @1 kHz, BW: 20 - 20 kHz
- Frequency Response
- 20Hz to 20kHz: +0/-0.7 dB
- Crosstalk
- Typ. < -95 dB, BW: 20 - 20 kHz
Other
- EMC
- EN-55103-1 and EN 55103-2, FCC part 15, Class B, CISPR 22, Class B
- Safety
- IEC 60065, EN 60065, UL6500, and CSA E60065 CSA File#108093
Environment
- Operating Temperature
- 32 F TO 122 F (0 C to 50 C)
- Storage Temperature
- -22 F TO 167 F (-30 C to 70 C)
- Humidity
- Max 90% non-condensing
Control Interface
- Finish
- Anodized aluminum front. Plated and painted steel chassis
- Display Dimensions
- 2x16 character back light LCD
- Mains Voltage
- 100 to 240 VAC, 50 to 60 Hz (auto-select)
- Power Consumption
- < 15W
