Spec
Generating Element: Dynamic N/Dym Magnet Structure
Frequency Response: 30 Hz - 18,000 Hz (kick curve) 45 Hz - 18,000 Hz (general curve)
Polar Pattern: Cardioid
Impedance: 150 ohms balanced
Sensitivity, Open Circuit Voltage, 1 kHz: 2.5 mV/pascal
Hum Pickup Level, typical (60 Hz/1 millioersted field): -130 dBm
Polarity: Pin 2 will be positive referenced to Pin 3 with positive pressure on diaphragm
Case Material: Steel
Dimensions: Length = 216.7 mm (8.53 in) Widest Diameter = 54.4 mm (2.14 in) Body Diameter = 49.2 mm (1.94 in)
Finish: Semi-Gloss Black
Weight: 681 g (1 lb, 8 oz)
Frequency Response: 30 Hz - 18,000 Hz (kick curve) 45 Hz - 18,000 Hz (general curve)
Polar Pattern: Cardioid
Impedance: 150 ohms balanced
Sensitivity, Open Circuit Voltage, 1 kHz: 2.5 mV/pascal
Hum Pickup Level, typical (60 Hz/1 millioersted field): -130 dBm
Polarity: Pin 2 will be positive referenced to Pin 3 with positive pressure on diaphragm
Case Material: Steel
Dimensions: Length = 216.7 mm (8.53 in) Widest Diameter = 54.4 mm (2.14 in) Body Diameter = 49.2 mm (1.94 in)
Finish: Semi-Gloss Black
Weight: 681 g (1 lb, 8 oz)
