Spec
Input voltage: DC 5V/2.5A
Max Output:
Balanced: >15.1V/385 mW (@ 600 Ohm), >11.0V/1890 mW (@ 64 Ohm), >6.2V/1200 mW (@ 32 Ohm)
S-E: >>7.6V/98 mW (@ 600 Ohm), >7.4V/870 mW (@ 64 Ohm), >7.2V/1600 mW (@ 32Ohm)
THD & N:
Balanced: <0.006% (@ 360 mW/2.4V 16 Ohm)
S-E: <0.005% (@ 100 mW/1.27V 16 Ohm)
SNR:
Balanced: >121dBA (@ 15.2V)
S-E: >120dBA (@ 7.6V)
Max. Input:
Balanced: 7.4V RMS
RCA: 3.8V RMS
3.5mm: 1.92V RMS
Gain: 0dB, 6dB, 12dB and 18dB
Frequency Response: 10Hz - 200kHz (-3dB)
Power consumption: No Signal ~5W
Max Signal ~12W
Dimensions: 158 x 117 x 35 mm
Net weight: 550 g
Max Output:
Balanced: >15.1V/385 mW (@ 600 Ohm), >11.0V/1890 mW (@ 64 Ohm), >6.2V/1200 mW (@ 32 Ohm)
S-E: >>7.6V/98 mW (@ 600 Ohm), >7.4V/870 mW (@ 64 Ohm), >7.2V/1600 mW (@ 32Ohm)
THD & N:
Balanced: <0.006% (@ 360 mW/2.4V 16 Ohm)
S-E: <0.005% (@ 100 mW/1.27V 16 Ohm)
SNR:
Balanced: >121dBA (@ 15.2V)
S-E: >120dBA (@ 7.6V)
Max. Input:
Balanced: 7.4V RMS
RCA: 3.8V RMS
3.5mm: 1.92V RMS
Gain: 0dB, 6dB, 12dB and 18dB
Frequency Response: 10Hz - 200kHz (-3dB)
Power consumption: No Signal ~5W
Max Signal ~12W
Dimensions: 158 x 117 x 35 mm
Net weight: 550 g
