Spec
Four stereo input pairs, each with Left / TRS input and Right / Mono input
One stereo output pair, with Left / TRS and Right outputs
Output level control that ranges from -∞ to +6dB
Dry mute button mutes input 4
Input impedance: 50k ohms, output impedance: 150 ohms
Internally generated +/-15V supply allows for best performance and headroom
Second power jack allows for daisy chaining
Dimensions: 4″ x 4″ x 1.5″ / 10.2cm x 10.2cm x 3.8cm
Weight: 10.3oz (300 g)
Power Requirements: 9VDC, center negative @ 150mA
