特徴
- 現代的で控えめなデザイン
- 高出力性能
- 明瞭度のあるサウンド
- 過負荷保護回路
- 70V/100Vトランス付きモデル
- 縦向き設置、横向き設置に対応
- 110x80の広指向性
- 壁付けブラケット同梱
Spec
- TYPE
- Ultra-Compact passive two-way system, front ported bass reflex
- FREQUENCY RESPONSE
- 90Hz-17kHz ± 3dB -10dB @ 65Hz
- DRIVERS
- LF: 5.25” /1” high-temp voice coil, coated paper, cone, rubber surround, ferrite motor, pressed steel chassis HF: 0.75” silk dome, neodymium motor
- RATED POWER
- 50W AES, 200W peak
- RECOMMENDED AMPLIFIER
- VIA2004
- SENSITIVITY
- 90dB/1W/1m
- MAXIMUM SPL
- 113dB peak
- NOMINAL IMPEDANCE
- 16Ω
- DISPERSION (-6DB)
- 110° H x 80° V
- CROSSOVER
- 3.5kHz passive (LF and HF auto-resetting fuses)
- RECOMMENDED HIGH-PASS FILTER
- 60Hz 24dB/oct
- ENCLOSURE
- ABS, UL 94V-0 rated
- FINISH
- Black or white
- GRILLE
- Perforated steel
- CONNECTORS
- Push terminals
- FITTINGS
- Wall bracket included
- DIMENSIONS EXCL. BRACKET
- (W) 152mm x (H) 245mm x (D) 140mm (W) 6in x (H) 9.6in x (D) 5.5in
- WEIGHT
- 2.21kg (4.9lbs)
- ACCESSORIES
- Waterproof connector cover Water resistant grille
