Spec
Input Connectors: 1/4" TRS and XLR, Floating Balanced; XLR: Pin 2 hot Phone: Tip Hot HI
Input Impedance: 40kΩ balanced/unbalanced
Max Input: +22dBu
CMRR: >40dB (Any Frequency)
Sidechain: 1/4" TRS Phone, Normalled: Ring = Output (send); tip = Input (return)
Sidechain Impedance : >10kΩ
Sidechain Output Impedance: ≤2kΩ
Sidechain Max Input Level: +21dBu
Output Connectors: 1/4" TRS phone and XLR floating balanced, XLR: Pin 2 and Tip Hi
Output Impedance : 200Ω balanced, 100Ω unbalanced
Max Output: +21dBu into 600Ω
Frequency Response : Flat: 20Hz-20kHz, +0, -0.5dB
Noise : <-93dBu unweighted
THD+Noise : Typically <0.2%; Any Amount of Compression @1kHz
IMD Typically : <0.2% SMPTE
Compressor Threshold Range : -40dBu to +20dBu
Compressor Threshold Characteristic : Selectable OverEasy® or hard knee
Compressor Ratio : 1:1 to Infinity:1
Compressor Attack Time : Scalable program-dependent
Compressor Release Time : Scalable program-dependent
Expander/Gate Threshold Range : -60 to +10dB
Expander/Gate Ratio : 1:1 to 4:1
Expander/Gate Max Depth : >60dB
Expander/Gate Attack Time : <100μs
Expander/Gate Release Time : Adjustable, 30ms to 3sec (to 30dB attenuation)
Limiter Threshold Range : 0dBu to +20dBu
Gain Adjustment Range : Variable; -20dB to +20dB
Interchannel Crosstalk : <-93dB @ 1kHz
Dynamic Range : >114 dB, unweighted
Stereo Coupling : True RMS Power Summing™
Power Consumption : 15 Watts Maximum
Dimensions : 1.75" x 19" x 6.75" (4.45 cm x 48.2 cm x 17.15 cm)
Unit Weight : 5 lbs (2.3 kg)
Input Impedance: 40kΩ balanced/unbalanced
Max Input: +22dBu
CMRR: >40dB (Any Frequency)
Sidechain: 1/4" TRS Phone, Normalled: Ring = Output (send); tip = Input (return)
Sidechain Impedance : >10kΩ
Sidechain Output Impedance: ≤2kΩ
Sidechain Max Input Level: +21dBu
Output Connectors: 1/4" TRS phone and XLR floating balanced, XLR: Pin 2 and Tip Hi
Output Impedance : 200Ω balanced, 100Ω unbalanced
Max Output: +21dBu into 600Ω
Frequency Response : Flat: 20Hz-20kHz, +0, -0.5dB
Noise : <-93dBu unweighted
THD+Noise : Typically <0.2%; Any Amount of Compression @1kHz
IMD Typically : <0.2% SMPTE
Compressor Threshold Range : -40dBu to +20dBu
Compressor Threshold Characteristic : Selectable OverEasy® or hard knee
Compressor Ratio : 1:1 to Infinity:1
Compressor Attack Time : Scalable program-dependent
Compressor Release Time : Scalable program-dependent
Expander/Gate Threshold Range : -60 to +10dB
Expander/Gate Ratio : 1:1 to 4:1
Expander/Gate Max Depth : >60dB
Expander/Gate Attack Time : <100μs
Expander/Gate Release Time : Adjustable, 30ms to 3sec (to 30dB attenuation)
Limiter Threshold Range : 0dBu to +20dBu
Gain Adjustment Range : Variable; -20dB to +20dB
Interchannel Crosstalk : <-93dB @ 1kHz
Dynamic Range : >114 dB, unweighted
Stereo Coupling : True RMS Power Summing™
Power Consumption : 15 Watts Maximum
Dimensions : 1.75" x 19" x 6.75" (4.45 cm x 48.2 cm x 17.15 cm)
Unit Weight : 5 lbs (2.3 kg)
