Spec
Input impedance: > 1MΩ
Output Impedance: ～100Ω
Ratio: 1:1 to inf:1
SENSE Threshold: Lo: ‐40dBu, Hi: user settable from ‐40dBu to 10dBu
Make-up gain: -20dB to +20dB
0dB input referrence level: -20dBu (77.5mV)
Output noise: -95dBV @0dBV gain
THD: 0.05% for -5dBV input signal level @ 1kHz
Output frequency response: -2dB @ 40Hz; 0dB @ 100Hz - 22KHz
Optimal Power Voltage: 9-12VDC ±10% Center Negative Barrel
DC Power Plug Barrel: 直径 5.1/2.1mm, 12-15mm long
Power Consumtion: < 25mAh
Product Size: Lenght: 39mm, Depth: 92mm, Height: 51mm
Product Weight: 163g
Output Impedance: ～100Ω
Ratio: 1:1 to inf:1
SENSE Threshold: Lo: ‐40dBu, Hi: user settable from ‐40dBu to 10dBu
Make-up gain: -20dB to +20dB
0dB input referrence level: -20dBu (77.5mV)
Output noise: -95dBV @0dBV gain
THD: 0.05% for -5dBV input signal level @ 1kHz
Output frequency response: -2dB @ 40Hz; 0dB @ 100Hz - 22KHz
Optimal Power Voltage: 9-12VDC ±10% Center Negative Barrel
DC Power Plug Barrel: 直径 5.1/2.1mm, 12-15mm long
Power Consumtion: < 25mAh
Product Size: Lenght: 39mm, Depth: 92mm, Height: 51mm
Product Weight: 163g
