Spec
Microphone Input
- Microphone Input: 2x balanced, XLR. Pin 2: hot / Pin 3: cold / Pin 1: ground
- Microphone Input Level: from 6 mVpp to 1.4 Vpp
- Microphone Input Impedance:3,2 kOhms
- Gain Range: 50 dB
- Phantom Power: +48V ± 4V
- Frequency Response: 20 Hz to 20 kHz (+-1.5dB)
- Input Noise:-103 dB(A), -97 dB RMS
Instrument Input
- Instrument Input: 2x unbalanced, Hi-Z, TS 1/4" Jack, Tip: signal / Shield: ground
- Instrument Input Level: from 30 mVpp to 6.9 Vpp
- Instrument Input Impedance: 1 MOhms
- Gain Range: 27 dB
- Frequency Response:
・ from 2 Hz to 21 kHz (-3dB) Gain @ min
・ from 5 Hz to 21 kHz (-3dB) Gain @ max - Input Noise:
・ -104 dB(A) Gain @ min
・ -102 dB(A) Gain @ max
Line Output
- Line Outputs:2x balanced, TRS 1/4" Jack, Tip: hot / Ring: cold / Shield: ground
- Floating Balanced Outputs with automatic level compensation when working in unbalanced mode
- Maximum Output Level: +16 dBu into 600 Ohms balanced load
- Frequency Response: from 10 Hz to 21 kHz (-3dB)
- Output Dynamic Range: 106 dB(A)
- Output Impedance: 150 Ohms balanced
Common
- AD and DA Resolution: 24-bit
- Sampling Rate: 44.1 kHz and 48 kHz
- Power: USB bus power, battery power (2xAA - included), or DC power supply (9VDC, from 500mA up, positive outside - not included)
- Metering:Multicolor LED)
- Size: 75mm/2.95" x 127mm/5" x 37mm/1.46"
- Weight: 197.2g/6.96oz (batteries excluded)
- Battery Life:
・ Recording - Max load*: 3 hours, 30 minutes (NiMH rechargeable); 45 minutes (Alkaline)
・ Playback - Min load**: 10 hours (NiMH rechargeable); 3 hours (Alkaline)
Package includes
- iRig Pro Duo universal dual channel Audio-MIDI interface
- Lightning to Mini-DIN connection cable (60cm/23.62")
- USB-C to Mini-DIN connection cable (60cm/23.62")
- USB to Mini-DIN connection cable (60cm/23.62")
- 2x 2.5mm TRS male to MIDI female adapter (10cm/3.9")
- 2 x 1.5V AA Battery
Dimensions
- Size: 75mm/2.95" x 127mm/5" x 37mm/1.46"
- Weight: 197.2g/6.96oz (batteries excluded)
- Lightning to Mini-DIN connection cable: 60cm/23.62"
- Micro-USB-OTG to Mini-DIN connection cable: 60cm/23.62"
- USB to Mini-DIN connection cable: 60cm/23.62"
- 2x 2.5mm TRS male to MIDI female adapter: 10cm/3.9"
iOS Devices
Compatible with iPhone XS Max, iPhone XS, iPhone XR, iPhone X, iPhone 8 Plus, iPhone 8, iPhone 7 Plus, iPhone 7, iPhone SE, iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6, iPhone 5s, iPad Pro 10.5-inch, iPad Pro 12.9-inch (2nd generation), iPad Pro 9.7-inch, iPad Pro 12.9-inch (1st generation), iPad Air 2, iPad Air, iPad mini 4, iPad mini 3, iPad mini 2, iPad (6th generation), iPad (5th generation), iPod touch (6th generation). iOS 7.0 or later is required.
Computers
Mac®: Mac OS X 10.6 or later. One free USB port.
Windows®: One free USB port. For low latency, the IK Multimedia's iRig audio driver must be installed.
Android Devices
Compatible with Android devices running Android 5 or later and with USB digital audio capabilities.
