Spec
- Frequency Response (1 Watt @ 1m)
- ±3 db 66 Hz to 18 kHz
- -10 dB 55 Hz
- Axial Sensitivity (dB SPL, 1 Watt @ 1m)
- Full Range 98
- Bi-amped LF 98
- Bi-amped HF 104
- Impedance (Ohms)
- Full Range 8
- Bi-amped LF 8
- Bi-amped HF 8
- Power Handling, AES Standard (Watts)
- Full Range 500
- Bi-amped LF 500
- Bi-amped HF 200
- Calculated Maximum Output (dB SPL @ 1m)
- Full Range Peak 131.0
- Bi-amped LF Peak 131.0
- Bi-amped HF Peak 133.0
- Full Range Long Term 125.0
- Bi-amped LF Long Term 125.0
- Bi-amped HF Long Term 127.0
- Nominal Coverage Angle, -6 dB Points (degrees)
- Conical 90
- Recommended High-Pass Frequency
- 24 dB/Octave 50 Hz
- Weights
- 33.7kg
