Spec
Input Impedance : 500k ohms
Output Impedance : less than 10k ohms
Equivalent Input Noise : less than -100dB (input shorted, IHF-A weighted)
Maximum Output Level: +10dB (typical)
Tone Control Range (Bass) : 100Hz 0 to 28dB (typical)
(Mid-boost): 1kHz 0 to 25dB (typical)
(Treble) : 3kHz 0 to 22dB (typical)
Noise Reduction Ratio : 1: 2 or more (approx.)
Tube: selected dual triode tube
Power Consumption: 175mA at 10VDC / 165mA at 9VDC
Dimensions : 110(W) x 160(D) x 72(H) mm
Weight : 600g
Power Supply: Maxon AC adaptor AC210 ( or AC310 ) for 100VAC
* 0dB = 0.775Vrms
* Specifications are subject to change without notice.
