Spec
| Load Impedance | 2 Ω | 2.7 Ω | 4 Ω | 8 Ω |
| Maximum Output Power, Single Channel | 3200 W | 2700 W | 1800 W | 950 W |
| Maximum Output Power, Dual Channel | 3000 W | 2500 W | 1700 W | 900 W |
| Maximum Output Power, Bridged | - | - | 6000 W | 3400 W |
- Maximum RMS Voltage Swing THD = 1%, 1 kHz
- 90.6 V
- Voltage Gain Ref.1 kHz
- 32.0 dB
- THD at 1200 W/4 Ω MBW = 80 kHz, 1 kHz
- < 0.05%
- IMD-SMPTE, 60 Hz, 7 kHz
- < 0.1%
- DIM30, 3.15 kHz, 15 kHz
- < 0.05%
- Maximum Input Level
- +21 dBu
- Crosstalk ref. 1 kHz, at 100 W/4 Ω
- < -80 dB
- Frequency Response, ref. 1 kHz
- 10 Hz to 21 kHz (±1 dB)
- Input Impedance, Active Balanced
- 20 k Ω
- Signal to Noise Ratio Amplifier, A-weighted, ref to Max. Output Power @ 8 Ω
- > 109 dB
- Output Noise, A-weighted
- < -68 dBu
- Output Stage Topology
- Class H
- Power Requirements
- 240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured)
- Power Consumption ⅛ Maximum Output Power @ 4 Ω
- 850 W
- Mains Fuse
- 240 V/230 V: T15AH; 120 V/100 V: T30AH
- Protection
- Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, Inrush current limiters, Turn on delay
- Cooling
- Front-to-rear, 3-stage-fans
- Ambient Temperature Limits
- +5°C to +40°C (40°F to +105°F)
- Safety Class
- I
- Color
- Black
- Dimensions (W x H x D), mm
- 483 x 88 x 462.4
- Weight
- 18.2 kg (40.1 lb)
- Signal Processing
- FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance
- Remote Control
- SONICUE sound system software **
- Accessories
- RMK15 (rear rack mount kit)
