Spec
- Main Features
- HEDD Lineariser®, CoP, GDC, LFE, Desk and Shelf Filters
- DSP Integration
- Custom high-resolution 96 kHz / 32 Bit AD / DA converter
- Drivers
- 2-Way: 7" Woofer (1,5" voice coil) + HEDD AMT Tweeter
- Power
- 2x100 W ICEpower amplification (85-264 V)
- Crossover
- 2.300 Hz
- Frequency Range
- 38 Hz - 40 kHz (LFE: 30 Hz - 40 kHz)
- Maximum SPL
- 116 dB SPL (sound pressure level) per pair at 1m
- Inputs
- Analog (XLR / 22 kΩ) and Digital 2ch (AES / XLR)
- Output
- Digital AES pass-through via XLR
- Dimensions and Weight
- 370 x 220 x 300 mm, 9.9 kg per unit
