Spec
- Class A (DSOP2) Output specs. Frequency response: 20Hz to 20kHz +- 0.5dB, Maximum Output = +26dBu @ 1kHz, Noise = -90dB @ 20Hz to 20kHz.
- Output connections: XLR’s and TRS 1/4″ Jack on rear
- Phoenix Audio’s unique Class A, transformerless, True balanced Mic input stage. Microphone inputs: XLR’s on Front and Rear Panels
- 10K mic impedance for high quality performance with all mic particualry ribbons mics & dynamic mics
- Transformer-balanced Output on each channel: Driven by the Phoenix Audio Class A DSOP-2 fully discrete output stage, each transformer is custom wound.
- Individual Earth Lift: Push-button Switches
- Gain Range (Mic input): -30 to -70 in 5dB steps With 10dB more available on the fader.
- Gain reduction: -15dB push-button pad switch (Mic input only)
- High Input Impedance DI: Mono 1/4″ Jack on front panel
- Gain Meter: LED Metering. (Green = 0dB, Red= +8dB, corresponding to "4" and "6" on a PPM Meter).
- Phantom Power: Switchable phantom on Push-button Switche
- High Pass Filter: on Push-button Switch
- Vari-filter control 70hz to 400hz on a 21 postion detented control
- Phase Reverse: on Push-button Switch
- Frequency Response Mic Input Stage: -0.4dB @ 40Hz, -0.3dB @ 25kHz
- Frequency Response: DI Input Stage: -0.3dB @ 40Hz, - 0.5dB @ 25kHz
- Typical Headroom: +26dB on Mic-Pre stage
- DI Stage gain: Maximum of 30dB
- Gyratory-based EQ Frequency Centres: (4 Bands) High - 25K 15K, 10K, Hi Mid - 6K, 3K, 1K6, Low Mid - 800Hz, 400Hz, 200Hz, Low - 130Hz, 80Hz, 40Hz
- EQ Cut/Boost Levels: 16dB Cut/Boost Per Band with fully detented pots in 21 positions
- All units are wired with PTFE silver military grade cable
- 110V仕様
