Spec
- Q
- 0,5
- THD+N @ +4dBu
- 0.003%
- THD+N @ +26dBu
- 0.0005%
- THD @ +4dBu
- 0.002%
- THD @ +26dBu
- 0.0005%
- Frequency response
- 20Hz-20kHz@ +/-0dB
- Frequency response
- 20Hz-80kHz@ -0.2dB
- Max input level
- +26dBu
- Max output level before clip
- +27dBu
- Signal to noise ratio @ 0dBu
- 94dBu
- Dynamic range
- 120dB
- Low freq
- 28Hz, 48Hz, 72Hz, 132Hz, 195Hz, 255Hz, switchable between shelf and peak
- Mid freq
- 400Hz, 630Hz, 870Hz, 1.3kHz, 2.4kHz, 4.8kHz
- High freq
- 4kHz, 7.2kHz, 12kHz, 16kHz, 20kHz, 25kHz, switchable between shelf and peak
- HPF freq
- 20Hz, 25Hz, 30Hz, 35Hz, 40Hz, 45Hz, or 100Hz, 125Hz, 150Hz, 175Hz, 200Hz, 225Hz with the x5 switch activated. -12dB/octave
- Boost/cut
- -4dB, -3dB, -2dB, -1dB, -0.5dB, 0dB, +0.5dB, +1dB, +2dB, +3dB, +4dB
- Level
- -4dB, -3dB, -2dB, -1dB, -0.5dB, 0dB, +0.5dB, +1dB, +2dB, +3dB, +4dB
- EQ
- in/out
- M/S
- in/out
Cue switch for separate monitoring of the mid or side signal
Regulated, internal power supply with a toroidal transformer
115V
