AKAI MPC1000

Storage: Compact Flash: Type-II, support up to 2GB card
Hard Drive (optional - req. HDM-10): any standard IDE 2.5" hard drive
Memory: 16MB installed (Can be expanded to 128MB with EXM-128)
Analog Input/Output:
(2) Balanced 1/4" Inputs
(6) Unbalanced 1/4" Outputs [Stereo L/R + 4 Assignable Outs]
(1) Headphone Output
Digital Input/Output:
(1) Coaxial S/PDIF Input [RCA]
(1) Coaxial S/PDIF Output [RCA]
MIDI Input/Output:
(2) MIDI Input [5-pin DIN]
(2) MIDI Output [5-pin DIN]
Other Input/Output:
(2) 1/4" Footswitch
(1) USB [Storage Support]
Levels:
Analog Input = +10dBu
Analog Output = +17dBu [Stereo & Assignable Outs]
Sampler Resolution: 16bit/44.1kHz
Sampler Recording Time:
136sec [16MB/MONO]
24min 28sec [128MB/MONO]
Sequencer Details:
100,000 notes resolving at 96ppq
99 Sequences with total 64 tracks per seq
20 Songs with total 250 steps per song
Pad Details:
16 (velocity and pressure sensitive)
4 Pad Banks [A, B, C, D]
Synchronization: MIDI Clock only
Power Options:
100v - 240v
50/60Hz
19W
Dimensions (W x H x D):
13" x 2.97" x 8.98"
330mm x 75.5mm x 228.2mm
Weight (net):
7.6 lbs
3.45 kg
Data Compatibility:
MPC1000: SEQ, WAV, PGM
