Spec
- Main Features
- HEDD Lineariser®, CoP, GDC, LFE, var. phase and crossover
- DSP Integration
- Custom high-resolution 96 kHz / 32 Bit AD / DA converter
- Driver
- 8" Woofer (2" voice coil)
- Power
- 300 W ICEpower amplification (85-264 V)
- Frequency Range
- 24 Hz - 200 Hz (LFE: 19 Hz - 200 Hz)
- Maximum SPL
- 105 dB SPL (sound pressure level) per unit at 1m
- Inputs
- Analog (XLR / 22 kΩ) and Digital 2ch (AES / XLR)
- Outputs
- Filtered Analog (XLR / 22 kΩ) and Digital AES pass-through
- Dimensions and Weight
- 392 x 290 x 400 mm, 17 kg
