Spec
Polar pattern | omni | |
Acoustic operating principle | pressure gradient transducer | |
Frequency range | 40 Hz bis 18.000 Hz | |
Sensitivity at 1 kHz | 14 mV/Pa | |
Output impedance | 100 Ohm | |
Noise level | DIN EN 60268-4 | 15 dB-A |
SPL for THD 0,5 % | 146 dB | |
Total dynamic range of the microphone preamplifier BMV 100 | 131 dB | |
Current consumption | 3,3 mA | |
Output connector | BMK 190 | 4-pin LEMO connector 00 |
BMV 100 | XLR3M | |
Length connection cable | 5 m | |
Weight | 290 g | |
Length of capsule BMK 190 | 64 mm | |
Diameter | of microphone | 21 mm |
Surface | dark bronze |
