Spec
Device type
- Optical Compressor
- Yes
Basic features
- Stereo Link
- Yes, for a custom order
- Hard wire bypass
- Yes
Input & Output
- Input Impedance (balanced)
- 600 ohm
- Output Impedance (balanced)
- 600 ohm
- Audio transformers
- Yes, Carnhill, Sowter, Edcor (sidechain)
Levels
- Operating Level
- +4 dBu
- Max input level
- +20 dBu
- Max output level
- +21 dBu
- Dynamic Range
- 100 dB
- Noise Level
- -99 dBA
- Max. gain
- 32 dB
- Max Gain Reduction
- 32dB
Time constants
- Ratio
- 4:1 in COMP mode, 100:1 in LIM mode
- Attack:
- 10ms
- Release:
- 0.5 - 5s (50% @ 60ms)
Bandwidth
- Frequency response
- 8 Hz - 20k Hz, +/- 1 dB
Distortion (@ 20 Hz - 20 kHz)
- THD+N
- 0.002% @ 0dBu
Front Panel
- VU Meters
- Yes, GR (backlit)
Power
- Voltage
- API Standard, internal DC-DC conversion for powering tubes (250V DC)
- Power consumption
- 8W
Packing box
- Shipping weight
- 3 kg
Others
- Tube set
- ECC802, ECC803
