Spec
Basic features
- Number of slots
- 1
- HPF
- OFF, 50 Hz (6dB/oct)
Input & Output
- Input Impedance (balanced)
- >1k2
- Input Pad
- -20dB
- Phantom Power
- Yes
- Input Pad
- -20dB, interstage
- Output Impedance (balanced)
- 600 Ohm
- Audio transformers
- Sowter / Edcor
Levels
- Operating Level
- +4dBu
- Max input level
- +16dBu
- Max output level
- +28dBu
- Dynamic Range
- 117dB
- Noise Level
- -100 dBA
- Max. gain
- 64dB
Bandwidth
- Frequency response
- 20Hz - 20kHz, - 1 dB
Distortion (@ 20 Hz - 20 kHz)
- THD+N
- max 0.5%
Power
- Voltage
- +/- 16V DC
- Power consumption
- 6.5W
Packing box
- Dimensions
- 78x166x229mm
- Shipping weight
- 2kg
