Spec
- TYPE
- Ultra-compact, passive two-way system
- FREQUENCY RESPONSE
- 70Hz-20kHz ± 3dB (-10dB @ 60Hz)
- DRIVERS
- LF: 8" (200mm)/2" (50mm) voice coil, ferrite motor system
- HF: 1inch (25mm) exit/1" (25mm) voice coil, polyester dome
- compression driver
- RATED POWER
- 200W AES, 800W peak
- RECOMMENDED AMPLIFIER
- MA2.8Q, MA2.0
- SENSITIVITY
- 92dB
- MAXIMUM SPL
- 115dB continuous, 121dB peak
- NOMINAL IMPEDANCE
- 8 ohms
- DISPERSION (-6dB)
- 90° H x 50° V (user-rotatable)
- CROSSOVER
- 2.9kHz passive
- ENCLOSURE
- Multi-angle birch/poplar ply
- FINISH
- Black textured paint
- PROTECTIVE GRILLE
- Black perforated steel with scrim cloth backing
- CONNECTORS
- 2 x NL4 type
- PIN CONNECTIONS (INPUT)
- 1+/1-
- PIN CONNECTIONS (LINK)
- 1+/- to 1+/-
- FITTINGS
- 13 x M8, 6 x M6 inserts, pole-mount socket, 1 x pocket handle
- DIMENSIONS
- (W) 257mm x (H) 422mm x (D) 243mm
- WEIGHT
- 8kg
- ACCESSORIES
- Wall bracket, eyebolts
