Spec
- Gain
- 0dB (+/- 0.5dB)
- Input impedance
- >1.5kohm
- Output impedance
- 150ohm
- Max. output level
- +22dBu (0.8% THD)
- Frequency response
- 5Hz - 65kHz (-3dB)
- SNR ratio
- 90dB
- LOW BOOST
- max +18dB
- LOW CUT
- max -18dB
- HIGH BOOST
- max +20dB
- HIGH CUT
- max -18dB
- LOW BOOST
- 20, 30, 60, 100, 120, 250 Hz
- LOW CUT
- 20, 30, 60, 100, 120, 250 Hz
- HIGH BOOST
- 1, 1.5, 2, 3, 4, 5, 6, 8, 10, 12, 16, 20 kHz
- HIGH CUT
- 2, 4, 6, 12, 16, 20 kHz
- AC mains
- 115(60Hz) / 230V(50Hz)
- Dimensions
- 88 x 483 x 237 mm/Case Rack 2U
