NEUMANN KH 420 G

KHシリーズ / ミッドフィールドモニター

アコースティカル、エレクトロニック、メカニカルデザインなど最新のテクニックを使用して、オーディオの再生品質において新たなベンチマークをもたらすことに成功しました。

コンピューターによって最適化されたドライバー、Mathematically　Modeled Dispersion(MMD) を特徴としたウェーブガイド、そして柔軟なアコースティカルコントロール、種々のインプットオプションと拡張性に富んだ取付けハードウェアレンジにより、KH 420 がどのようなソース機器の多様な音響条件、そして様々な物理的な配置でも使用可能です。KH 420 は、ミッドフィールドまたはメインモニターとして使用するために設計されています。トラッキング、ミキシング、そしてマスタリングなどのミュージック、放送、およびポストプロダクションスタジオでの使用に特に適しています。
KH 420 は、フリー-スタンディングまたは壁にフラッシュマウント、そしてマルチチャンネルシステムですることができ、自由に他のスピーカーと組合せての使用もできます。

税別価格¥790,000-
税込価格¥869,000-

送料無料!!

沖縄及び離島,遠隔地は除きます

両店扱い,新品です

受注発注品です。

お問い合わせはこちらから!

To customers live in overseas!

メーカーサイトはこちら

数量：

Spec

Free field frequency response ±6 dB: 25 Hz … 22 kHz
Free field frequency response ±3 dB: 26 Hz … 22 kHz
Free field frequency linearity deviation between 100 Hz and 10 kHz: ± 1.2 dB
Self-generated noise at 10 cm (with input gain set to 100 dB SPL for 0 dBu): <20 dB(A) SPL
Sine wave output with a THD < 0.5 % at 1 m in half space: 95 dB SPL (>100 Hz)
Max. SPL calc. in half space at 3% THD at 1m (averaged between 100 Hz and 6 kHz): 122.4 dB SPL
Max. SPL in full space at 3% THD at 1m (averaged between 100 Hz and 6 kHz): 116.4 dB SPL
Bass capability: Max. SPL in half space at 3% THD at 1m (averaged between 50 Hz and 100 Hz): 109.9 dB SPL
Max. short term SPL with IEC-weighted noise (IEC 60268-5) at 1 m, in typical listening conditions: 109 dB(C) SPL
Reproduction accuracy between 100 Hz and 10 kHz: 100%, 80%, 50% of loudspeakers produced: ±0.78; ±0.36; ±0.22 dB
Max. short term SPL with music material at 2.3 m in typical listening conditions (pair / full range): 103 dB(C) SPL
Max. short term SPL with music material at 2.3 m, in typical listening conditions (pair with subwoofer): 109 dB(C) SPL
Max. long term SPL with pink noise at 2.3 m, in typical listening conditions (single / pair full range): 90 / 96 dB(C) SPL
Max. long term SPL with pink noise at 2.3 m, in typical listening conditions (single / pair with subwoofer): 90 / 96 dB(C) SPL
Equalization: Mid: 0; -1.5; -3; -4.5 dB
Equalization: Parametric EQ: Gain: '+4 ... -12 dB
Equalization: Parametric EQ: Frequency: Bypass, 25 ... 80 Hz; 50 ... 160 Hz; 100 ... 320 Hz
Equalization: Parametric EQ: Q: 1 ... 8
Display Brightness: White: 100%/60%/30%/off; Red: 100%/60%/30%
Output power midrange amplifier (THD+N with limiter deactivated: 10%): 140 W
Output power midrange amplifier (THD+N with limiter deactivated: 0.1%): 130 W
Midrange: 75 mm (3") with magnetic shielding
Cabinet weight when electronics remote located: 30.3 kg (66 lbs 13 oz) (+ 100 g (3 oz) with DIM 1 fitted)
Bass Extension (Hz, -6 dB): 25
Maximum output level (dB SPL): 116.4
Max. Listening Distance up to (m): 11
Analog input(s): XLR: analog electronically balanced
Analog input impedance: >14k Ohms
Max. input level: +24 dBu (DIM 1: 18 dBu for analog delayed)
Common mode rejection ratio (CMRR): >56 dB @ 15kHz
Input gain control (sensitivity): 0 dB ... -15 dB
Output level control (output level in 1 m based on 0 dBu input level): 94; 100; 108; 114 dB SPL
Equalization: Bass: 0; -2.5; -5; -7.5 dB
Equalization: Treble: +1; 0; -1; -2 dB
Controller design: Analog; active
Crossover frequency: 570 Hz and 2.0 kHz
Crossover slope: 24 dB/oct; 4th order
Protection circuitry: Independent thermo limiters for woofer, midrange dome and tweeter. Woofer soft clip and excursion limiters. Amplifier overheat.
Infrasonic filter: frequency; slope: 9 Hz; 18 dB/oct.
Display: On; Normal Operation: Neumann logo “White”
Display: Limit / Clip / Errors / Protection /Boot Mute / Shut Down Mute: Neumann logo “Red”
Output power woofer amplifier (THD+N with limiter deactivated: 10%): 330 W
Output power tweeter amplifier (THD+N with limiter deactivated: 10%): 140 W
Output power woofer amplifier (THD+N with limiter deactivated: 0.1%): 295 W
Output power tweeter amplifier (THD+N with limiter deactivated: 0.1%): 130 W
Mains Power Supply: input voltage; frequency: 100-240V; 50/60 Hz
Power consumption (230 V / 100 V): Idle: 60 W (+5W when DIM 1 fitted)
Power consumption (230 V / 100 V): Full output: 800 W
Cabinet material: Wood cabinet, polyurethane waveguide, aluminum electronics panel
Cabinet surface finish; color (front / back): Painted; metallic anthracite (RAL 7021) / black (RAL 9005)
Operating conditions: +10° C to +40° C (+50° F to +104° F); <90% RH, non-condensing
Transport/storage conditions: -25° C to +70° C (-13° F to 158° F); <90% RH; non-condensing
Woofer: 265 mm (10") with magnetic shielding
Tweeter: 25 mm (1") with protecting black metal grille
Mounting points: 8 x M5 on rear panel
Product dimensions (height x width x depth): 645 x 330 x 444 mm (25 3/8" x 13" x 17 1/2")
External net volume: 93 liters
Packed dimensions (height x width x depth), mm (inches): 775 x 610 x 590 mm (30 1/2" x 15" x 14 1/8")
