Spec
Polar pattern | cardioid | |
Acoustic operating principle | pressure gradient transducer | |
Frequency range | 20 Hz to 20.000 Hz | |
Sensitivity at 1 kHz | 23 mV/Pa | |
Output impedance | 40 Ohm | |
Noise level | CCIR 468-4 | 18 dB |
DIN EN 60268-4 | 7 dB-A | |
Signal-to-noise ratio | CCIR weighted | 81 dB |
A-weighted | 87 dB | |
SPL for THD 0,5 % | 142 dB | |
Max. output level | R = 1 kOhm | 18 dBu |
R = 10 kOhm | 21 dBu | |
Dynamic range | 135 dB | |
> 60 dB | ||
Current consumption | 6 mA | |
Output connector | XLR3M | |
Weight | 273 g | |
Length | 130 mm | |
Diameter | 45 mm | |
Surface | satin nickel, dark bronze |
