特徴
- 超小型CDD™パッシブ2WAYシステム
- 同軸非対称拡散テクノロジー
- エレガントなABS樹脂エンクロージャー
- 直接雨などにさらされることのない環境下での屋外使用可
- -20°C to +70°Cの温度環境下で使用可能
- IP54に合致する環境テスト済
- 回転可能な同軸ドライバーユニット
- 縦向き、横向きに設置可能な金具をご用意
- はめ込み式耐水、耐塵グリル
- ノミナルインピーダンス8Ω
- 目立ちにくい耐水取り付け金具
Spec
- TYPE
- Compact, Coaxial Differential Dispersion passive two-way system
- FREQUENCY RESPONSE (5)
- 65Hz-20kHz ± 3dB
- 10dB @ 55Hz
- DRIVERS
- LF: 10" (250mm)/2.5" (63.5mm) voice coil, long excursion, shared ferrite motor system with HF
- HF: 1" (25mm) exit/1.4" (38mm) voice coil, polyimide dome compression driver
- RATED POWER (2)
- 250W AES, 1000W peak
- RECOMMENDED AMPLIFIER
- MA2.0
- SENSITIVITY (8)
- 96dB
- MAXIMUM SPL (9)
- 120dB continuous, 126dB peak
- NOMINAL IMPEDANCE
- 8 ohms
- DISPERSION (-6dB)
- 110°-75° horizontal, 60° vertical (user-rotatable)
- CROSSOVER
- 2kHz passive
- ENCLOSURE
- 28 litre, composite material
- FINISH
- Black or white as standard
- PROTECTIVE GRILLE
- Zinc plated mild steel with powder coated finish and weatherised backing
- ENVIRONMENTAL
- Rated at IP54
- CONNECTORS
- Low profile 20A push-lock, weatherproof input panel cover with dual cable glands
- PIN CONNECTIONS
- Left to right: Input+, Input -, Link -, Link +
- FITTINGS
- 6 x M8 inserts for wall bracket
- 10 x M8 fly points
- DIMENSIONS
- (W) 323mm x (H) 513mm x (D) 310mm
- (W) 12.7ins x (H) 20.23ins x (D) 12.2ins
- WEIGHT
- 15.5kg (34.2lbs)
- ACCESSORIES
- CDDWB10/12B wall bracket black
- CDDWB10/12W wall bracket white
- CDDYA10B yoke assembly black
- CDDYA10W yoke assembly white
