Spec
- API 500 series 互換ラックユニット
- Class A (DSOP2) Output specs . Frequency response: 20Hz to 20kHz +- 0.5dB,
- Maximum Output gain = +15dBu @ 1kHz, Noise = -90dB @ 20Hz to 20kHz, maximum output from unit is +26db.
- Input connections: XLR input on rear of API compatible rack
- Phoenix Audio’s unique Class A, transformer-less, True electronically balanced buffer amp input stage.
- コンプレッサー部コントロール:
- Threshold Settings: From +10db to -30db
- Ratio Settings: From 2 to 8
- Release Settings: Release time of 0.1 seconds to 3 seconds
- コンプレッサー部スイッチ
- Bypass : engages or bypasses compressor section
- Fast : Fast or slow release times
- Auto : Auto release of compression
- ゲート部コントロール:
- Threshold Settings: From 0db to -40db
- Range Settings: From 40 to 10
- Release Settings: Release time of 0.1 seconds to 2 seconds
- ゲート部スイッチ
- Link: Ability to link multiple modules (up to 8).
- Key: External input for gate section, connector is a TT Bantam connector
- Gate: Switches the Gate in and out
- Compression Meter: LED Metering. (Green = -3dbu, -6dbu -10dbu & -14dBu, Red=
- -20dBu and doubles as the Gate Active LED)
- Typical Max Headroom: +26dB on output stage
