特徴
- 2チャンネルの効率的なクラスDパワーアンプ
- 総出力2500W
- 2Uラックマウント
- 超軽量
- スイッチモードパワーサプライ
- 前吸い込み後ろ排気の速度可変型ファンを搭載
- 100V~230Vのユニバーサル電源
- 包括的な保護回路
- 信号インジケーターとクリップインジケーターにLED採用
Spec
- TYPE
- Two-channel Class D amplifier
- POWER OUTPUT(*)
- 2 x 1250W into 2 ohms
- 2 x 800W into 4 ohms
- 2 x 450W into 8 ohms
- 1 x 2500W bridged into 4 ohms
- COOLING
- Vari-speed fans, front-to-back airflow
- MAXIMUM AMBIENT TEMPERATURE
- 40°C (105°F)
- ANALOGUE IN/LINK (4 CHANNELS)
- 2 x female, 2 x male Neutrik™ XLR
- ANALOGUE INPUT IMPEDANCE
- 10kΩ Balanced
- MAXIMUM ANALOGUE INPUT LEVEL
- +20dBu
- AMPLIFIER OUTPUTS
- 2 x Neutrik Speakon™ NL4
- OUTPUT NOISE
- >-113dBA, referenced to max output
- (22kHz bandwidth)
- FREQUENCY RESPONSE
- <10Hz ->20kHz +/- 0.25dB
- TOTAL HARMONIC DISTORTION
- 0.003% typical, 1kHz @ 1W
- SLEW RATE
- > 80V per microsecond
- DAMPING FACTOR
- >120 ref 8 ohms
- POWER SUPLLY TYPE
- High current, high frequency switch-mode
- AC INPUT OPERATING RANGE
- 100-240V +/-10%
- 45 - 65Hz
- TOTAL SYSTEM EFFICIENCY
- > 90% typical
- MAINS CONNECTOR
- 1 x Neutrik Powercon™
- DIMENSIONS
- (W) 482 x (H) 2U/88mm x (D) 441mm
- (W) 19in x (H) 2U/3.5in x (D) 17.4in
- incl handles and optional rear support
- WEIGHT
- 8kg (17.6lbs)
