Spec
- Transducer type
- Dynamic
- Operating principle
- Pressure gradient
- Frequency response
- 40 - 18,000 Hz
- Polar pattern
- Figure-eight
- Rear attenuation at 1 kHz
- > 30 dB at 90°
- Open circuit voltage at 1 kHz (0 dB = 1 V/Pa)
- 1.3 mV/Pa = -57.5 dBV
- Nominal impedance
- 200 Ω
- Load impedance
- >= 1000 Ω
- Diaphragm
- Pure aluminium
- Case/finish
- Brass
- Connector
- XLR, 3-pin, male
- Dimensions
- Length: 128 mm
Shaft diameter: 23 mm
Head diameter: 38.5 mm - Weight without cable
- 150 g
