Spec
Input impedance: 500k Ohm
Recommended output load: 50k Ohm or higher, effects output and buffer output
Current consumption: 6mA at 9VDC
DC supply voltage range: 8-18V
Voltage gain: +40 dB
Treble boost: peak +15 dB@4k Hz
Signal to noise ratio: 110 dB
Effect 3dB bandwidth: 70 Hz to 7k Hz
True bypass or buffered (switchable inside the pedal)
Power: 006P/6F22 9V バッテリー or パワーサプライ(センターマイナス/2.1 mmプラグ)
Recommended output load: 50k Ohm or higher, effects output and buffer output
Current consumption: 6mA at 9VDC
DC supply voltage range: 8-18V
Voltage gain: +40 dB
Treble boost: peak +15 dB@4k Hz
Signal to noise ratio: 110 dB
Effect 3dB bandwidth: 70 Hz to 7k Hz
True bypass or buffered (switchable inside the pedal)
Power: 006P/6F22 9V バッテリー or パワーサプライ(センターマイナス/2.1 mmプラグ)
