Spec
MANLEY input transformer with nickel laminations potted in mu-metal case.
3 kOhm input Z
PHASE REVERSE switch for balanced XLR input
Alternate transformerless 1/4" HI-Z (5K Ohm) input
BYPASS switch & AUTO-MUTE w/warmup delay
Silent conductive plastic BOOST & CUT controls
Sealed gold-contact Greyhill frequency select switches
Vacuum Tubes: 1 x 12AX7 (gain) and 1 x 12BH7 (or 6414 or 5965) White Follower
Hi-current drive <50 Ohm LO-Z XLR & 1/4" outputs
Balanced Transformer-Coupled XLR Outputs via MANLEY 9611
Flat frequency response from 10Hz-70KHz<0.01% THD @ 1kHz
S/N Ratio: 116 dB
Adjustable FEEDBACK / GAIN: Unity ±5 dB
Max. output: +30 dBv
Power consumption: 18 watts
Operating mains voltage: Units are purpose built for original destination country's mains voltage: 100V, 120V, or 220-240VAC as indicated on the serial number badge. Power transformer must be replaced in order to change mains operating voltage. 120VAC units may NOT be rewired to put the primaries of the power transformer in series for 220-240V operation or a large radiated field of hum will develop. If changing locations/voltages, the power transformer must be replaced with the dedicated one for the voltage at which it will operate.
Mains Voltage Frequency: 50～ 60Hz
Dimensions: 19" x 3 1/2" x 10" (occupies 1u)
Shipping weight: 12 lbs.
3 kOhm input Z
PHASE REVERSE switch for balanced XLR input
Alternate transformerless 1/4" HI-Z (5K Ohm) input
BYPASS switch & AUTO-MUTE w/warmup delay
Silent conductive plastic BOOST & CUT controls
Sealed gold-contact Greyhill frequency select switches
Vacuum Tubes: 1 x 12AX7 (gain) and 1 x 12BH7 (or 6414 or 5965) White Follower
Hi-current drive <50 Ohm LO-Z XLR & 1/4" outputs
Balanced Transformer-Coupled XLR Outputs via MANLEY 9611
Flat frequency response from 10Hz-70KHz<0.01% THD @ 1kHz
S/N Ratio: 116 dB
Adjustable FEEDBACK / GAIN: Unity ±5 dB
Max. output: +30 dBv
Power consumption: 18 watts
Operating mains voltage: Units are purpose built for original destination country's mains voltage: 100V, 120V, or 220-240VAC as indicated on the serial number badge. Power transformer must be replaced in order to change mains operating voltage. 120VAC units may NOT be rewired to put the primaries of the power transformer in series for 220-240V operation or a large radiated field of hum will develop. If changing locations/voltages, the power transformer must be replaced with the dedicated one for the voltage at which it will operate.
Mains Voltage Frequency: 50～ 60Hz
Dimensions: 19" x 3 1/2" x 10" (occupies 1u)
Shipping weight: 12 lbs.
