Spec
- True Bypass
- Nominal Input Level
- -10dBV
- Pad Attentuation
- 10 dB
- Input Impedance
- 1 Mohms
- Frequency Response +0 / -3 dB
- 35 - 20k Hz
- Gain Range
- -oo/+26 dB
- Bass Filter Range
- 0-15 dB < 80 Hz
- Middle Filter Range
- 0-12 dB @ 400 Hz
- Treble Filter Range
- 0-6 dB @ 5 kHz
- Output Impedance
- 100 ohms
- Nominal Output Level
- Unbalanced: -10 dBv
- Balanced: -20 dBv
- Dimensions (L x W x H)
- 6.5" x 5.3" x 3.0"(165 x 135 x 75 mm)
- Weight
- 960 g (2.1 lbs.)
- Power Requirements
- 9 V DC, 700 mA (power supply included)
