Spec
- Nominal Input Level
- - 8 or -20 dBv (active/passive)
- Input Impedance
- 1 Mohms
- Pedal Modes
- Wah or Volume
- Frequensy Response
- +3/-3 dB
- 20 – 20.000 Hz
- Filter Center Frequency Range
- 50 – 12.500 Hz
- Filter Q
- min/max
- 4.5 / 16
- Filter Mode
- Low, Band, Boosted Band, and High Pass
- Output Impedance
- 200 ohms
- True Bypass
- Yes
- Dimensions (L x W x H)
- 10.6" x 3.7" x 3.0"
- (270 x 95 x 75 mm)
- Weight
- 1.8 kg (4 lbs.)
- Power Requirements
- 9 V DC Regulated, 25 mA max.
