spec
Nominal Input Level - 8 dBv
Input Impedance 700 kohms
Dry Bandwidth +0 / -3 dB 20 - 20k Hz
Effect Bandwidth +0 / -3 dB 60 - 7 kHz
Dist gain range 6 - 70 dB min.
Types Standard, Flat, Tubesim
Dimensions (L x W x H) 2.8 x 4.5 x 1.4" (70 x 115 x 35 mm)
Weight 400g (0.88 lb.)
Power Requirements 9V - 12V DC Regulated, 25 mA max.
Input Impedance 700 kohms
Dry Bandwidth +0 / -3 dB 20 - 20k Hz
Effect Bandwidth +0 / -3 dB 60 - 7 kHz
Dist gain range 6 - 70 dB min.
Types Standard, Flat, Tubesim
Dimensions (L x W x H) 2.8 x 4.5 x 1.4" (70 x 115 x 35 mm)
Weight 400g (0.88 lb.)
Power Requirements 9V - 12V DC Regulated, 25 mA max.
