Spec
- Channels (mono + stereo)
- 5 + 3
- Microphone inputs
- 5 x XLR/Jack socket
- Auxiliaries (FX, AUX)
- 1 Post, 1 Pre
- Max. single channel output power, dynamic headroom, IHF-A
- into 4 Ω
- 640 W
- into 8 Ω
- 350 W
- Max. dual channel output power, dynamic headroom, IHF-A
- into 4 Ω
- 2 x 600 W
- into 8 Ω
- 2 x 340 W
- Max. single channel output power, continuous, 1 kHz, THD = 1%
- into 4 Ω
- 500 W
- into 8 Ω
- 280 W
- Max. midband output power, 1 kHz, THD = 1%, dual channel
- into 4 Ω
- 2 x 450 W
- into 8 Ω
- 2 x 270 W
- Rated output power, 20-20000 Hz, THD < 0.5%, one channel loaded
- into 4 Ω
- 400 W
- into 8 Ω
- 240 W
- Max. output power, Direct Drive mode (bridge configuration), continuous, 1 kHz, THD = 1%
- into 12 Ω
- 680 W
- Max. output voltage, power amplifier, 1 kHz, no load
- Dual channel mode
- 52 Vrms
- Direct Drive mode
- 100 Vrms
- THD, at 1 kHz, MBW = 22 kHz
- MIC input to master A L/R outputs, +10 dBu, typical
- < 0.015%
- MIC input to speaker output
- < 0.15%
- Frequency response, -3 dB, ref. 1 kHz
- Any input to any Mixer output
- 15-22000 Hz
- Any input to Speaker output
- 15-22000 Hz
- Crosstalk, 1 kHz
- Amplifier Ch1/Ch2
- < -85 dB
- Channel to channel
- < -78 dB
- Microphone mute switch attenuation
- > 100 dB
- Channel VOL and FX/AUX send attenuation
- > 85 dB
- CMRR, MIC input, 1 kHz
- > 80 dB
- Input sensitivity, all level controls in max. position
- MIC
- -65 dBu (435 μV)
- LINE (mono)
- -45 dBu (4.35 mV)
- LINE (stereo)
- HI: -27 dBu (34.6 mV), LO: -11 dBu (218 mV)
- CD (stereo)
- -27 dBu (34.6 mV)
- Output impedances
- PHONES
- 47 Ω
- All other outputs (impedance balanced)
- 150 Ω
- Power consumption, at 1/8 maximum output power, 4 Ω
- 180 W
- Operating temperature
- 5° to 40° C (40° to 105° F)
- Product dimensions (Width x Height x Depth)
- 395 x 244 x 241 mm
Rack-mount: 483 x 223 x 310.3 mm (7 HU) - Net weight
- 4.9 kg
- Shipping weight
- 6.4 kg
