特徴
- 6chディスクリートJDIパッシブDI
- Jensenトランス搭載
- 10Hz-40k Hzまでウルトラリニアな高音質
- 極めて低歪み
- 高いヘッドルーム
- フロントパネル入力搭載(CH1&2)
- チャンネル数を節約可能なMerge機能
- 高い耐久性
Spec
- Audio circuit type
- Passive, transformer based
- Number of channels
- Six channels
- Frequency response
- 20Hz ～ 20KHz (± 0.2dB)
- Dynamic range
- 135dB
- Maximum input
- +21dB @ 20Hz
- Total harmonic distortion
- 0.05% from 20Hz ～ 20kHz @-10dB
- Phase deviation
- 0.3° @ 100Hz; 3° @ 20Hz
- Input impedance
- 140k Ohms, unbalanced
- Output impedance
- 150 Ohms, balanced
Features
- Transformer
- JENSEN JT-DB-EPC
- Shield
- MuMETAL® can with internal Faraday shield
- Input pad
- -15dB
- Merge
- Sums left & right sources to mono (ch. 1 & 2 only)
- 180° polarity reverse
- Inverts absolute phase
- Ground lift
- Disconnects pin-1 at XLR output
- XLR configuration
- AES standard (pin-2 hot)
- Connectors (ch. 1 & 2)
- RCA L/R in, 1/4" in & thru, XLR-M out
- Connectors (ch. 3 ～ 6)
- 1/4" in & thru, XLR-M out
General
- Construction
- 14 gauge steel chassis & outer shell
- Finish
- Durable powder coat
- Size (W x H x D)
- 483 x 44.5 x 159mm ("19" x 1.75" x 6.25")
- Weight
- Looking for this spec
- Shipping size (W x H x D)
- 260 x 114 x 568mm (10.25" x 4.50" x 22.37")
- Shipping weight
- 3.7 kg (8.15 lbs)
- Power
- Passive, no power required
- Conditions
- For use in dry locations only between 5°C and 40°C
