Spec
- Tube based push-pull amplifier
- Freq. resp. @ -3 dB: 5 Hz – 55 kHz
- Low noise: < -80 dBU @ 0 dB gain
- CMRR: > 60 dB @ 10 kHz
- All-tube active/passive EQ
- FILTERS:
- Low cut: 18, 25, 40, 60, 85 Hz, 6db/octave
- Low shelving: 18, 37, 80, 180, 370, 800 Hz. Gain: +/-12dB
- High shelving: 1, 2, 5, 10, 15, 22 kHz Gain: +/-12dB
- T.-filter: 0,5, 1, 2kHz. Gain: +4/-7 dB
- High cut: 12, 15, 18, 20, 25 kHz, 6db/octave
- Tracking between channels: +/-0,3 dB
- Input impedance: >10 kΩ
- Output impedance: < 60Ω
- Conductive plastic potentiometers
- In- and output are transformer balanced and fully floating
