Spec
- Threshold Range
- Infinite to +20 dBu, Continuously Adjustable
- Maximum Output Level
- > + 32 dBu
- Maximum Input Level
- + 30 dBu
- Output Gain Control
- Continuously Adjustable
- Frequency Response
- +0 / -3 dB sub 5 Hz to 100 kHz
- Noise (20 Hz - 22 kHz)
- -87 dBu (SS), -82 dBu (VT)
- Attack Range
- 2 ms to 100 ms, Continuously Adjustable
- Release Range
- 100 ms to 3.0 S, Continuously Adjustable
- Compression Ratio Range
- minimum 1.4 : 1, maximum 30 : 1, Continuously Adjustable
- THD + Noise (20 Hz - 30 kHz)
- < .01 %, typ .003 % (VT or SS)
- Common Mode Rejection Ratio (10 Hz - 20 KHz, 100 mV C.M.)
- > 50 dB, Typ > 70 dB
- Dynamics Bypass For Each Channel?
- Yes
- Meter Gain Reduction Or VU Selection?
- Yes
- Stereo Linking Switch?
- Yes
- Input Impedance
- 25k Ohms
- Minimum Output Load Impedance
- 300 Ohms (SS), 1k Ohms (VT)
- Recommended Minimum Load
- 600 Ohms (SS), 3k Ohms (VT)
- Output Impedance
- < 5 ohms (SS), < 300 ohms (VT)
- Twin Topology Compressor Amplifiers
- Switch In: Pure Class-A Discrete J-FETs
- Switch Out: Pure Class-A Triode Tubes
- Power Consumption
- 55 watts maximum
- Power Requirements
- Selectable: 100-120, 200-240 V ac, 50/60 Hz
- Dimensions/Shipping Weight
- 19” W x 12.5” L x 3.5” H, 26 lbs.
