Spec
- Type
- Side Address, Supercardioid Electret Condenser.
- Frequency Response
- 10-18 kHz (See Back Cover).
- Polar Pattern
- Supercardioid (See Back Cover).
- Impedance
- Low (200 ohms nominal).
- Output Level At 1 kHz
- Power Level: -34 dB (0 dB = 1 mW per 10 microbars).
- Open Circuit Voltage: -55 dB (0 dB = 1 volt per microbar).
- 17.8 mV/Pascal.
- Dynamic Range
- 132 dB.
- Equivalent Noise Level
- 16 dB Equivalent SPL, A weighted.
- Maximum Output Level
- With pad: .89 dBV.
- Without pad: 8.9 dBV.
- Maximum SPL
- 148 dB SPL (With pad on).
- Total Harmonic Distortion
- Less than 0.15%.
- Signal-To-Noise Ratio
- 78 dB (At 94 dB SPL).
- Capsule Capacitance
- 60 pF.
- Powering
- Minimum Requirements are 48 - 52 Volts Phantom Power capable of delivering at least 8 mA.
- Connector
- Three pin male XLR type.
- Finish
- Durable black urethane. Brass plated front screen.
- Dimensions
- 2.45" (62.2 mm) Wide x 6" (153.4 mm) High x 2.175" (55.2 mm) Deep.
- Net Weight
- 18 oz. (510 grams).
