Spec
Rated Output Power: 600 watts @ 4 ohms, 450 watts @ 8 ohms
Frequency Response: 10Hz - 40kHz -1dB
Preamp: Tube Low Noise 12AX7A High-Mu Twin Triode
Active Input: >1MΩ unbalanced, -10dBV, -8dBu
Passive Input: >1MΩ unbalanced, -20dBV, -18dBu
Compressor Ratio: Fixed 2.1
Compressor Threshold: Off to -30dBu Passive Input, Off to -20dBu Active Input
Mute: >80dB (100dB typical) at Direct Output & Speaker Output
Brite Switch: 10kH, +8dB Gain @ 2 o’clock; +5dB Gain @ min
Tone Stack EQ
Bass +8/-14dB, 80 Hz relative to 12 o’clock
Shape +11/-3dB relative to 12 o’clock
Frequency 200Hz to 800Hz
Treble +5/-20dB, 6kHz relative to 12 o’clock
Preamp Output: 100Ω unbalanced 0dBu
Power Amp: In 20kΩ balanced, 0dBu for Rated Output Power (+14dBu max input)
Direct Output: 125Ω balanced
Stereo Aux Input: 3kΩ unbalanced, 10dBV
Phones: 80mW max, shuts off Direct Output & Speaker Output
Dimensions: 14” x 10.6” x 2.6” / 355mm x 270mm x 66mm
Weight: 7 lb / 3.2 kg
Frequency Response: 10Hz - 40kHz -1dB
Preamp: Tube Low Noise 12AX7A High-Mu Twin Triode
Active Input: >1MΩ unbalanced, -10dBV, -8dBu
Passive Input: >1MΩ unbalanced, -20dBV, -18dBu
Compressor Ratio: Fixed 2.1
Compressor Threshold: Off to -30dBu Passive Input, Off to -20dBu Active Input
Mute: >80dB (100dB typical) at Direct Output & Speaker Output
Brite Switch: 10kH, +8dB Gain @ 2 o’clock; +5dB Gain @ min
Tone Stack EQ
Bass +8/-14dB, 80 Hz relative to 12 o’clock
Shape +11/-3dB relative to 12 o’clock
Frequency 200Hz to 800Hz
Treble +5/-20dB, 6kHz relative to 12 o’clock
Preamp Output: 100Ω unbalanced 0dBu
Power Amp: In 20kΩ balanced, 0dBu for Rated Output Power (+14dBu max input)
Direct Output: 125Ω balanced
Stereo Aux Input: 3kΩ unbalanced, 10dBV
Phones: 80mW max, shuts off Direct Output & Speaker Output
Dimensions: 14” x 10.6” x 2.6” / 355mm x 270mm x 66mm
Weight: 7 lb / 3.2 kg
