Spec
Conductor Size : 0.25mm2
Construction(No./mm) : 50/0.08OFC
Diameter : 0.65mm
Insulation Thickness : 1.93mm(±0.05)
Diameter : 4.50mm
Inner Jacket-Thickness : 0.25mm
Diameter : 5.00mm
Shield-Diameter : 5.50mm
Jacket-Thickness : 0.75mm(±0.10)
Diameter : 7.00mm
Maximum conductor resistance (20°C) : 70.70≧(Ω/km)
Capacitance(1kHz) : Approx.55(pF/m)
Plug : NP-14GおよびNP-14GL(L型プラグ)
Construction(No./mm) : 50/0.08OFC
Diameter : 0.65mm
Insulation Thickness : 1.93mm(±0.05)
Diameter : 4.50mm
Inner Jacket-Thickness : 0.25mm
Diameter : 5.00mm
Shield-Diameter : 5.50mm
Jacket-Thickness : 0.75mm(±0.10)
Diameter : 7.00mm
Maximum conductor resistance (20°C) : 70.70≧(Ω/km)
Capacitance(1kHz) : Approx.55(pF/m)
Plug : NP-14GおよびNP-14GL(L型プラグ)
