Spec
- Application
- Pole-mounted / monitor / kick-back
- Transducers
- 12” woofer, ferrite magnet
1” compression driver, neodymium magnet, ferrofluid cooled - Power rating (peak)
- 400 W
- SPL max1
- 126 dB
- Coverage (H x V)
- 100° x 60°
- Frequency range (-10 dB)2 / response (-3 dB)3
- 45 Hz - 20 kHz / 55 Hz - 20 kHz
- Material
- Enclosure: polypropylene
Grille: steel with powder coat - Digital signal processing
- QuickSmartDSP features best-in-class processing powered by Dynacord. Easy setup via seven-band GEQ for main EQ, user-programmable presets, visual monitoring of limiter status, input level control and meters, digital effect control, and master volume control to optimize gain structure, all via LCD or the free QuickSmart Mobile app.
- Remote control and monitoring
- EV QuickSmart Mobile application: quickly and wirelessly configure, control and monitor up to six EVERSE 12 systems simultaneously, and receive immediate notification during critical performance conditions.
- Bluetooth audio streaming and true wireless stereo4
- YES
- Crossover frequency
- 2000 Hz
- Connectors
- 2x XLR/TRS combo jack 1x charge port 1x XLR output 1x 12 V DC power output 1x 3.5mm stereo 1x TRS footswitch
- USB charging
- 1.5 A max, device-dependent
- Power consumption5
- 100 - 240 V～, 50 - 60 Hz, 1.2 - 0.6 A
- Battery capacity
- 86.4 Wh
- Battery at max output6
- 6+ hours of run optimize6+ hours of run time
- Battery at moderate output7
- 12+ hours of run time
- Weight
- 14.16 kg (31.22 lbs)
- Dimensions (W x H x D)
- 345 mm x 597 mm x 347 mm (13.58" x 23.5" x 13.66")
- Kick-back / monitor angles
- 25° / 55°
- Colors
- Black
- Accessories
- EVERSE12-TRAY-B mic receiver tray black
EVERSE-BAT-B battery pack black
EVERSE-DUFFEL padded duffel bag
EVERSE12-RAINCVR rain cover
