Spec
- Frequency response (-3 dB) 1
- 60 Hz to 20 kHz
- Frequency range (-10 dB) 2
- 50 Hz to 20 kHz
- Max. SPL 3
- 121 dB
- Coverage angle (H x V)
- 100° x 100°
- Amplifier rating
- 400 W
- LF transducer
- 8 in. woofer - ferrite magnet
- HF transducer
- 1 in. titanium dome, neodymium magnet, ferro-fluid cooled
- Crossover frequency
- 2.5 kHz
- Connectors
- 2 - XLR/TRS Combo
1 - 3.5mm Stereo
1 - Charge port
1 - TRS footswitch
1 - 12 V DC power output - Enclosure
- Polypropylene
- Grille material
- Powder coated steel
- USB charging
- 1.5 A max., device-dependent
- Color
- Black & white
- Dimensions (H x W x D)
- 400 mm x 275 mm x 272 mm
15.75 in. x 10.83 in. x 10.71 in. - Net weight
- 7.6 kg
16.8 lb - Shipping weight
- 11 kg
24.3 lb - Power consumption 4
- 100 - 240 V~, 50 - 60 Hz, 0.8 - 0.6 A
- Battery capacity
- 86.4 Wh
- Battery run time (at max output) 5
- 6+ hours
- Battery run time (at moderate output) 6
- 12+ hours
2 Half-space measurement.
3 Maximum SPL is measured at 1 m using broadband pink noise at maximum output.
4 Current rating is 1/8 power.
5 Maximum output before loudspeaker limit indication, with typical program material.
6 Moderate output is approximately 95 dB SPL, with typical program material.
