Spec
- Test Signal Path
- APx555 (Line Out) - Input - Line Output - APx555 (Line In)
- Max Input Level
- +26.0dBu (<0.003% THD)
- Max Output Level
- +26.0dBu (<0.003% THD)
- Noise Floor
- <-93dBu all bands bypassed
- Input Impedance
- Line = 10 kOhms
- Output Impedance
- Line = 150 Ohms
- Current Draw
- 140mA per rail - idle, 160mA peak
EQ Specifications
Hi Band
- Filter Type
- High Shelf Filter
- Frequency Range
- 5kHz - 25kHz
- Boost/Cut
- ±12dB, @ -6dBu、+13dB, -18dB, @ +14dBu
- Harmonics
- -8% THD+N (100Hz, +4dBu) -12% THD+N (100Hz, +14dBu)
Mid Band
- Filter Type
- Peak Filter
- Frequency Range
- 200Hz - 6.2kHz
- Boost/Cut
- ±5dB @ -6dBu +10dB, -18dB @ +14dBu
- Harmonics
- -8% THD+N (100Hz, +4dBu) -12% THD+N (100Hz, +14dBu)
Lo Band
- Filter Type
- Low Shelf Filter
- Frequency Range
- 20Hz - 420Hz
- Boost/Cut
- ±8.5dB @ -6dBu、±12dB @ +14dBu
- Harmonics
- -8% THD+N (100Hz, +4dBu) -12% THD+N (100Hz, +14dBu)
Hi Cut Filter
- Type
- Progressive slope low-pass filter
- Slope
- 1st order - 3db per octave
2nd order - 6db per octave
3rd order - 12dB per octave - Frequency Range
- -3db, 8kHz - 40kHz
Lo Cut Filter
- Type
- Progressive slope high-pass filter
- Slope
- 1st order - 6db per octave
2nd order - 12db per octave
3rd order - 18dB per octave - Frequency Range
- -3db, 18Hz - 180Hz
1/4" TRS Inserts
- Type
- Balanced, dedicated send & return, normalled
- Config
- Post M/S encoding & Carnaby, pre M/S decoding
- Max Input Level (return)
- +26.0dBu (<0.003% THD+N)
- Max Output Level (send)
- +26.0dBu (<0.003% THD+N)
Mid/Side
- Type
- Encoder/decoder
- Matrix
- Sum-difference matrix
Environmental
- Operating Temperature
- +1 to 35 degrees Celsius
- Storage Conditions
- -20 to 50 degrees Celsius
Dims/Weights
Unit
- Width
- 48.3cm (19”) (Rackmount)
- Height
- 8.9cm (3.5") (2u)
- Depth
- 23.6cm (9.3")
- Unit Weight
- 6kg (13lbs)
Shipping carton
- Width
- 60cm (23.6")
- Height
- 18cm (7")
- Depth
- 35cm (13.8")
- Carton Weight
- 6.5kg (14 lbs)
