Spec
Conductor Size : 0.18mm2
Construction(No./mm) : 16/0.12OFC
Diameter : 0.55mm
Insulation Thickness : 0.73mm(±0.05)
Diameter : 2.00mm
Inner Jacket Thickness : 0.25mm
Diameter : 2.50mm
Shield Diameter : 3.00mm
Jacket Thickness : 1.75mm(±0.10)
Diameter : 6.50mm
Maximum conductor resistance(20°C) : 100.00≧(Ω/km)
Capacitance(1kHz) : Approx.160(pF/m)
Construction(No./mm) : 16/0.12OFC
Diameter : 0.55mm
Insulation Thickness : 0.73mm(±0.05)
Diameter : 2.00mm
Inner Jacket Thickness : 0.25mm
Diameter : 2.50mm
Shield Diameter : 3.00mm
Jacket Thickness : 1.75mm(±0.10)
Diameter : 6.50mm
Maximum conductor resistance(20°C) : 100.00≧(Ω/km)
Capacitance(1kHz) : Approx.160(pF/m)
