Spec
- Input Impedance
- 8900 Ohms
- Input to Line Output (No Features Engaged, Un-weighted)
- Maximum Input Level: +23.6dBu
- Noise (Un-weighted)
- Line Out (Unity Gain): -102dBu
- -6dB Line Out (Unity Gain): -107dBu
- Line Out (+30dB Gain): -95dBu
- Equivalent Input Noise @ +30dB Gain (EIN): -125dBu
- Maximum Output Level @ 1kHz
- +23.6dBu
- Frequency Response
- <10Hz to 30kHz: +/- 0.1dB
- <5Hz to 70kHz: +/- 0.25dB
- <5Hz to 140kHz: -3dB
- THD+N, BW (<10Hz to 22kHz)
- 0dBu at 1 kHz: 0.0013%
- +20dBu at 1 kHz: 0.0007%
- Input to Line Output (Equalizer Engaged)
- Noise (BW <10Hz to 22kHz): -90dBu
- THD+N @ 0dBu (EQ Flat): 0.003%
- Input to Line Output (Compressor Engaged)
- Noise @ 0dB Make-Up Gain (BW <10Hz to 22kHz): -91dBu
- THD+N @ 0dBu (EQ Flat): 0.005%
- Compressor Section
- Attack Time: 20mS (fixed)
- Release Time: Variable; 50mS (Fast) to 500mS (Slow)
- PRODUCT DIMENSIONS (W x D x H)
- 19" (48.3 cm) x 8.125" (20.63 cm) x 1.75" (4.5 cm)
- SHIPPING DIMENSIONS (L x W x H)
- 24" (61 cm) x 13" (33 cm) x 4" (10.2 cm)
- SHIPPING WEIGHT
- 9 lbs. (4.1 kg)
