Spec
- Free field frequency response ±6 dB
- 53 Hz … 21 kHz
- Free field frequency response ±3 dB
- 57 Hz … 21 kHz
- Free field frequency linearity deviation between 100 Hz and 10 kHz
- ± 0.7 dB
- Self-generated noise at 10 cm (with input gain set to 100 dB SPL for 0 dBu)
- <20 dB(A) SPL
- Sine wave output with a THD < 0.5 % at 1 m in half space
- 90 dB SPL (>200 Hz)
- Max. SPL calc. in half space at 3% THD at 1m (averaged between 100 Hz and 6 kHz)
- 108.8 dB SPL
- Max. SPL in full space at 3% THD at 1m (averaged between 100 Hz and 6 kHz)
- 102.8 dB SPL
- Bass capability: Max. SPL in half space at 3% THD at 1m (averaged between 50 Hz and 100 Hz)
- 96.8 dB SPL
- Max. short term SPL with IEC-weighted noise (IEC 60268-5) at 1 m, in typical listening conditions
- 104 dB(C) SPL
- Reproduction accuracy between 100 Hz and 10 kHz: 100%, 80%, 50% of loudspeakers produced
- ±0.26; ±0.23; ±0.17 dB
- Max. short term SPL with music material at 2.3 m in typical listening conditions (pair / full range)
- 93 dB(C) SPL
- Max. short term SPL with music material at 2.3 m, in typical listening conditions (pair with subwoofer)
- 100 dB(C) SPL
- Max. long term SPL with pink noise at 2.3 m, in typical listening conditions (single / pair full range)
- 88 / 93 dB(C) SPL
- Dynamic range A-D
- 114 dB(A)
- Dynamic range A-D-A
- 111 dB(A) woofer; 112 dB(A) tweeter
- Dynamic range D-A
- 114 dB(A) woofer; 117 dB(A) tweeter
- Latency
- 2 ms (A-D-A linear phase)
- Max. long term SPL with pink noise at 2.3 m, in typical listening conditions (single / pair with subwoofer)
- 91 / 96 dB(C) SPL
- Display Brightness
- via Neumann.Control software; 4 positions
