Spec
Headphone
- Transducer type
- Dynamic
- Operating principle
- Closed
- Frequency response
- 5 - 35,000 Hz
- Nominal impedance
- 32 Ω per system
- Nominal SPL
- 96 dB
- T.H.D.
- < 0.2%
- Power handling capacity
- 100 mW
- Sound coupling to the ear
- Circumaural
- Ambient noise attenuation
- Approx. 18 dBA
- Headband pressure
- 3.5 N
- Weight with microphone and cable
- 332 g
- Cable length and type
- 1.2 m [3.9 ft] cable with remote control for the use with consoles
2.5 m [8.2 ft] cable with remote control for the use with a PC - Connection
- 1* 3.5 mm for consoles
2* 3.5 mm for PC
1* adapter 6.35 mm - Accessories
- 2 x detachable cables (console & PC)
1 x transport case
Microphone
- Transducer type
- Condenser (back electret)
- Operating principle
- Pressure gradient
- Polar Pattern
- Cardioid
- Power supply
- AB powering
- Supply voltage
- 1.5 - 9 V
- Current consumption
- < 0.5 mA
- Nominal impedance
- Approx. 1.5 kΩ
- Open circuit voltage at f = 1 kHz
- 20 mV / Pa
- Frequency response
- 30 - 18,000 Hz
- T.H.D.
- 0.2% at f = 1 kHz
- Max. SPL
- 120 dB
- Microphone output
- Unbalanced
- Dimensions
- Length mic boom: Approx. 150 mm
Capsule diameter: 13 mm - Connection
- Mini stereo jack plug (3.5 mm)
